Transcritical CO2 system’s efficiency boosted with hydrocarbon heat pump in Netherlands

December 12, 2022

Transcritical CO2 System’s Efficiency Boosted with Hydrocarbon Heat Pump in Netherlands

The COP of a transcritical CO2 (R744) heating and cooling system at a horticultural site in Maasbree, the Netherlands, has been improved by nearly 18% with the integration of a high-efficiency propane (R290) heat pump, according to a case study produced by the system’s suppliers and contractors.

The addition of the R290 unit has increased the system’s COP by 21.8% for cooling (to 2.475) and 14.6% for heating (to 3.475), bringing the overall COP to 5.95.

The horticultural site also plans to add an isobutane (R600a) unit to the system to increase output temperatures to 80°C (176°F), which will enable thermal storage.

The case study was presented by Alessandro Farina, Application Manager at component manufacturer Castel; André Dunnebier, Technical Manager at component supplier Euro-Cold; and Wil van den Kerkhof, Technical Director at contractor Servex, during an HVAC and heat pumps session at the ATMOsphere (ATMO) Europe Summit on natural refrigerants. The conference took place November 15–16 in Brussels and was organized by ATMOsphere, publisher of R744.com.

Integrating R290 with CO2

According to Dunnebier, the horticultural operator wanted a heating and cooling system that was free from fossil fuels and used only natural refrigerants. It also needed a system that could supply a range of temperatures, while still being energy- and cost-efficient, reliable and operational in any climate.

To meet these demands, a transcritical CO2 system with two gas coolers was chosen and integrated with an R290 heat pump, including a condenser that is connected to a subcooler to boost capacity and satisfy the customer’s requests.

The R290 heat pump operates at an evaporative temperature of 10°C (50°F) and condensing temperature of maximum 45°C (113°F), he added.

This is the second installation completed by Servex that has used R290 to subcool CO2 in transcritical mode, said van den Kerkhof.

He also explained that the system includes a special gas cooler that can work as an evaporator when the outside air is needed as the heat source for the CO2 system.

The CO2 system provides 770kW (218.9TR) in heating capacity and 516kW (146.7TR) in cooling capacity, but with the addition of the R290 heat pump, the total system capacity has been increased to 1,053kW (299.4TR) for heating and 750kW (213.3TR) for cooling.

In total, the system includes 1,800kg (3,968.3lbs) of R744 and 80kg (176.4lbs) of R290.

As detailed during the presentation, two Alfa Laval plate heat exchangers have been installed in the system: one to heat water from 30°C (86°F) to 37°C (98.6F) and the second to heat water up to 75°C (167°F).

The system also uses Bock compressors and various CO2 and R290 components from Castel.

According to van der Kerkhof, “technical improvement of system design and components is the key to making R744 and R290 the perfect solution for [an integrated] heat pump and cooling system.”

He added that subcooling with an R290 unit can be added to any existing CO2 system.

“It can make a bad CO2 system a good one,” he said.
